Transparent Insulation Electrical Potting Gel Silicone Liquid In Bulk

Name: Transparent Insulation Electrical Potting Gel Silicone Liquid In Bulk
Brand: Hanast
Price: 1 USD

China Transparent Insulation Electrical Potting Gel Silicone Liquid In Bulk wholesale

Brand Name : Hanast

Model Number : HN-6607AB

Certification : ROHS SGS

Place of Origin : Guangdong, China

MOQ : 1kg

Price : Negotiable

Payment Terms : T/T, D/A, D/P

Packaging Details : 25KG/barrel

Type : AB gel silicone

Application : electrical connector igbt load cell

Keyword : Transparent liquid silicone gel

Sample : 1kg

Feature : very soft ,clear,low-viscosity

Viscosity after mixing（cp s. 25℃) : 800～1500

Mix ratio : 1:1

Color : Transparent

Hardness : 0-10 shore A

Operate Time （25℃) : 2h

Contact Now

0 HardnessTransparent Liquid Silicone Gel For Electrical Connector Igbt Load Cell Waterproof AB Gel Squishy Gel Soft Liquid Silicone

Product Description:

This product is a very soft, low crosslinking density addition silicone rubber. It is a low-viscosity liquid before vulcanization. After vulcanization, in addition to the general characteristics of addition silicone rubber, it has good shock absorption, moisture resistance and sealing due to its soft nature. properties and excellent dielectric insulation properties over a wide range of temperature and humidity.

Transparent Insulation Electrical Potting Gel Silicone Liquid In Bulk

Characteristics before curing
Component	Component A	Component B
Color	Transparent liquid	Transparent liquid
viscosity(cp s. 25℃)	800～2000	800～1800
Relative density(mpa•s)	1 ．0～1.12	0.98～1.02
The mixing ratio	A:B=1:1
Viscosity after mixing(cp s. 25℃)	800～1500
Operate Time (25℃)	2 h
Penetration (1/10mm)	200~ 400
Curing conditions (120℃)	20~30 mins
Cured properties Hardness(Shore A, 24hr)	0～10

Product Features:

1. Medium temperature curing, the curing time can be adjusted according to different temperatures;

2. It is low-viscosity silicone oil before curing and gel elastomer after curing.

Transparent Insulation Electrical Potting Gel Silicone Liquid In Bulk

Instructions:

1. Before mixing, component A needs to be properly stirred manually or mechanically, and component B should be fully shaken in a sealed state before use.

2. When it needs to be attached to the application material, please confirm whether it can be attached before use, and then apply it. 3. Before construction, please weigh and mix according to the weight ratio of A:B = 1:1, and stir thoroughly before applying glue.

Transparent Insulation Electrical Potting Gel Silicone Liquid In Bulk
